Double bending head machine allowing multiple options for loading and feeding raw material. Pits retractable orientation clamp allows very small straight distance between the final 2 bends.
R2104TF | R2105TF | R2106TF | R2108TF | R2110TF | R2112TF | |
---|---|---|---|---|---|---|
Wire capacity at 600 N/mm² or 85 Ksi | .07 to .16" / 1,8 to 4 mm | .07 to .2" / 1,8 to 5 mm | .12 to .24" / 3 to 6 mm | .12 to .31" / 3 to 8 mm | .14 to .39" / 3,5 to 10 mm | .16 to .47" / 4 to 12 mm |
Main features
- From .065 to .47″ / 1,8 to 12 mm
- Wire
- 3D bending from precut lengths or coil
- Speed and higher quality for production of long and symmetrical parts
- Retractable central clamp allows to achieve extreme short distances (from 3″) between the 2 central bends
- Strong 3 position auxiliary clamp fitted on the heads (for guiding and transfer)
- Optional – Bending tool cetral axis rotation from model R2106 upwards. Revolving or biplane wire straightener as per request
- Modular machine allowing to evolve according to need
- Looping capability at both ends
- Optional independantly operating bending heads
Man / Machine interface
- Industrial-Grade PC powered by proprietary software
- Multilingual dialog and programming interface on a 19″ touch screen
- Simulation program
- Additional I/O
- Internet connection : remote assistance and chat room
- Auto-corrective feedback from 3D-measuring devices
- Tool editor allows programming of complex parts
- Simulation tool to facilitate part set-up
- Program execution in slow motion
